Strand pelletizing

Strand pelletizer for strand pelletizing and dry cut pelletizing for compound production – SGS 100/200/300-E6

SGS 100/200/300-E6

More than thousand machines in operation: The cantilvered pelletizers of the SGS-E series demonstrate their quality under the toughest production conditions for strand pelletizing and dry cut pelletizing — since the beginning of the 1980s. A sturdy and sophisticated design as well as many technical details for improved accessibility when cleaning and/or changing products reduce unproductive downtime and make the SGS-E the preferred pelletizer for production of masterbatches and small lots. The improved cutting geometry extends the production range especially when processing soft, elastic, and very brittle materials.

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

​​TECHNICAL DATA

  Parameters: Units: SGS 100-E6

 SGS 200-E6

SGS 300-E6
  Working width: mm 100 200 300
  Max. No. of strands: Ø 3 mm 20 40 60
Strand speed: m / min 20-80 20-80 20-80
  Type of drive: Frequency converter
  Power: kW 3,0 5,5 11,0
  Max. throughput (product-depently): 1,2kg / h 600 1200 2000
  Acoustic insulation: if required
