SGS 25-E4
The extremely compact and robust lab pelletizer SGS 25-E4 for strand pelletizing and dry cut pelletizing is based on the proven technology of the SGS E-series. It features many of the functions and advantages of its popular “big brothers.” On a laboratory scale, real full-scale trials can be carried out with the SGS 25-E4. Two independently- controllable frequency converters permit infinitely variable pellet length adjustment.
SGS 25-E4
SGS 25-E4
TECHNICAL DATA
| Working width: | 25 mm | |
| Drive power: | 0.75 kW | |
| Max. no. of strandsl 3 Ø 3 mm : | 3 Ø 3 mm | |
| Strand speed 1): | 5.3 - 30 m / min | |
| Throughput 2): | 30 kg / h | |
| Cutting edges bed knife: | 4 | |
| No. of teeth cutter rotor | 4, 6, 12 | |
| Max. RPM of cutter rotor | 1,000 UPM / RPM | |
| Noise level 3): | 75 - 80 dB (A) | |
| The limitation of use depends on the operating conditions. Please contact us for specifi c applications. 1) Optional: Low strand speed ranges for meeting special lab requirements with low output. 2) At 3 mm strand diameter, spec. gravity 1,0 g/cm³, strand speed 30 m/min. 3) Depends on product and strand speed. Technical Data are subject to change without notice |
||
