![Mechanical pressure gauge PG 4-row Mechanical pressure gauge PG 4-row](http://www.azurr-tech.cz/hu/file/bb851afc761bb08e843a9d5393c190e5/25496/bigperex/PG4%20Series%20Dynisco.png)
PG4 Series
Dynisco's series of mechanical pressure indicators is the ideal choice for applications that require simple and maintenance-free pressure indication. The polymer pressure is sensed by a diaphragm that is installed in the process orifice of the machine. In the fixed bar configuration, the display can be rotated 300 ° for a seamless overview. For applications with high temperatures or limited installation space, pressure gauges with a flexible capillary are available to keep the meter away from the process and radiant heat. Configurations that simultaneously sense temperature using thermocouples or RTD are also available.
Performance characteristics:
Combined error:
|
± 2% of sensor range
|
|
Zero setting:
|
7.5% of sensor range
|
|
Maximum pressure:
|
1.5x sensor range
|
|
Rotation angle of the display: | 270° | |
Thermocouple: | Typ J (Standard) |
Temperature and mechanical properties:
Maximum membrane temperature:
|
400°C
|
|
Maximum head temperature:
|
135°C
|
|
Case material:
|
Stainless steel with safety glass
|
|
Mounting torque: | 500 inches / pound. maximum | |
Weight: | 2-3 pounds. depending on the configuration | |
Standard soaked parts: | TiN coated 15-5 PH SST |
Dimensions:
![](/file/9f297708a71fdbf3fe03fa814da5485d/4753/image.png)
Certification Approval
![]() |
EU Declaration of Conformity |
![]() |
ISO 9001:2015 |
![]() |
EAC - The Eurasian Conformity mark |
|
|
|
|
