Model 24B Pressure Transducer

Model 24B Pressure Transducer

Viatran’s 24B is one of our most versatile pressure transducers for industrial applications. The 24B measures from 0-100 PSI to 0-30,000 PSI with standard linearity of ≤ ±0.25% FSO.


Full Scale Pressure Ranges:
0-100 thru 15,000 PSIG (PSIS FOR ≥ 1500 PSI) (7 thru 1000 bar)
Nonlinearity (Best Fit Straight Line)
≤±0.25% FSO
Hysteresis & Repeatability
≤±0.10% FSO
  Full Scale Output (FSO) 5 Vdc at 70°F (21°C) ≤±0.10% FSO
  Resolution Infinite

Long Term Stability

≤±0.3% FSO per 6 months
  Compensated Temperature Range 70°F to 170°F (21°C to 77°C)
  Process Media Temperature Range -40°F to 250°F (-40°C to 121°C)
  Ambient Operating Temperature Range -40°F to 185°F (-40°C to 85°C)
  Storage Temperature Limits -40°F to 250°F (-40°C to 121°C)
Temperature Effect on Zero ≤±2.0% FSO per 100°F
  Temperature Effect on Span ≤±2.0% FSO per 100°F


Supply Voltage:
8 to 30 Vdc at 3.5 mA nominal, 5 mA max
(12 to 30 Vdc for 10 Vdc output option
Power Supply Regulation
≤±0.01% FSO per volt change over the supply voltage range
  Output Signal 0 - 5 Vdc standard (see options)
  Zero Adjustment ±5% FSO min
  Circuit Protection

Input polarity may be reversed. Output may be short-circuited indefinitely Over voltage protection to 1000 volts according to EN61000-4-5

  Insulation Resistance <5 nSec to case ground
Response Time <2 mSec to reach 90% of full scale
RFI / EMI Suppression Bendix PT02E-10-6P, mates PT06E-10-6S (SR)
Electrical Connection Bendix PT02E-10-6P, mates PT06E-10-6S (SR)
Pin Outs Pin A + Power
Pin B - Power
Pin C + Signal
Pin D - Signal
Pin E No connection
Pin F No connection
Shell Groun



Pressure Connection
1/4" - 18 NPT female
Proof Pressure
1.5 times range or 20,000 PSI (1379 bar) max
  Burst Pressure 3 times range or 35,000 PSI (2400 bar) max
  Pressure Cavity Volume

4.5 ml

  Mounting May be supported by process piping




Wetted Materials:

Inconel X-750, heat treated per MR0175-2000

Enclosure Material:

304 stainless steel
Laser etched onto body
  Shock Limitation: 100 G’s
  Enclosure Rating: NEMA 4X
  Weight: 5.5 lbs nominal (2.4 kg)
  * Pending approvals
