PT 460 | 462 | TPT 463
The Dynisco PT460E Series is a ± 1.0% sensor ideal for melt pressure applications that require easy installation, repeatability and reliability. The PT460E transducers provide an industry standard 3.33 mV/V signal that is designed to work with most pressure indicators. The PT460E is equipped with a 6-pin Bendix connector. Optional thermocouples or RTD configurations are available to provide melt temperature and pressure in one location. The PT460E is UNF 1/2-20 threaded for mounting in the standard mounting holes of the transmitter and can be supplied with a number of other electrical connections if required.
PT 460 - Melt pressure sensor in a design with a fixed stem
PT 462 - Melt pressure sensor in a design with a flexible capillary
PT 463 - Melt pressure sensor in combined design with temperature sensor
MDA 460 Melt pressure sensors series
Standard process connection of 1 / 2-20 UNF sensor with diaphragm cover.
Adjusting screws - used to adjust the zero and upper range of the sensor
Sensor terminal and compatible cable connector
Detail - Bayonet cable connector Amphenol 6-PIN
PERFORMANCE CHARACTERISTICS
|
Pressure range:
|
0 - 30 000 psi
|
|
|
Accuracy:
|
± 1.0% FSO, (including linearity, repeatability and hysteresis) |
|
|
Overload capacity:
|
2X FSO or 35,000 psi, (whichever is less)
|
|
| Repeatability: | ± 0.2% FSO | |
| Sensor diaphragm: | Dymax® 15-5 PH SST | |
| Sensor connection: | 1/2"-20 UNF-2A nebo M18 x 1.5 | |
| Mounting torque: | 500 inch/lbs. maximum | |
| Sensor construction: | Fixed rod sensor (optional length) |
TEMPERATURE CHARACTERISTICS
|
Max. membrane temperature:
|
540°C
|
|
|
Zero shift (due to temperature):
|
27 psi/100°C
|
|
|
-------------------------------------------
|
------------------------------------------------------------------
|
|
| Max. sensor body temperature: | 121°C | |
| Zero shift (due to temperature) | ± 0.02% FS/°C max | |
| Displacement sensitivity (due to temperature) | ± 0.01% FS/°C max |
ELECTRICAL CHARACTERISTICS
|
Power supply:
|
10 Vdc - 12 Vdc
|
|
|
Output signal:
|
3.33 mV/V ± 2.0%
|
|
|
Zero setting:
|
± 10% FSO
|
|
| Connector: | 6 PIN konektor Bendix | |
| Insulation resistance: | 1000 megohms @ 50 Vdc | |
| Resistance calibration (R-Cal): | 80 % FSO |
ROZMĚRY SNÍMAČE:
 |
EU Declaration of Conformity for Flush Mount mV/V Output |
 |
ISO 9001:2015 |
 |
EAC - The Eurasian Conformity mark |
 |
GOST Approval |
 |
RoHS Compliance Fact Sheet |
 |
Safety Integrity Level - SIL2 |
