Temperature sensors

TG422J Dynisco Thermocouples

TG422J

Thermocouples are the most common and widely used devices used to measure temperature. The Dynisco TG422J thermocouples offer a versatile and cost-effective variant, making it a popular choice for extrusion applications in the plastics industry. Available in type J and with a 304 stainless steel construction, the probe can be straight or made at an angle of 45 ° or 90 °. Dynisco thermal thermocouples are designed and manufactured to applicable ISA standards with precision following the National Institute of Standard Technology (NIST).

TG422J - Dynisco temperature sensor

TG422J - Dynisco temperature sensor

Kabeláž k teplotnímu snímači

Kabeláž k teplotnímu snímači

Kabeláž k teplotnímu snímači

Kabeláž k teplotnímu snímači

Kabeláž k teplotnímu snímači

Kabeláž k teplotnímu snímači

Inquiry system

Configure your own product, according to your requirements and needs. If you are not sure about the configuration, tell us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative Dynisco product. If your request is urgent, let us know, we will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences, which is in stock and you can have the necessary product the next day.

Konfigurační kód

Vaše osobní údaje budou zpracovány podle Podmínek zpracování osobních údajů.

Thermocouple for General Extrusion Measurements

Melt Temperature Probe Series TG422J


Thermocouples are the most common, convenient and versatile devices used to measure temperature. Dynisco’s TG422J thermocouple offers economy and versatility, making it a popular choice for extrusion applications in the plastics industry. Available as type J and with 304 stainless steel sheaths, the probe can be straight or manufactured to either a 45° or 90° bend angle. Dynisco’s temperature thermocouples are designed and manufactured to applicable ISA standards with accuracy traceable to the National Institute of Standard Technology (NIST).



Features

Features

Type J thermocouple

0 to 900°F range

Fiberglass insulated element

Adjustable brass or bayonet fitting

Standard output

Wide range of measurements

Protects the wire

Application versatility





Ordering Guide for TG422J Series

TG422J - Dimensions

All dimensions are inches (mm) unless otherwise specified.
