BP520 - Burst plugs with indication
The BP520 series of pressure fuses have a "pop-up" indicator cap. A fine conductor passes through the construction of the fuse and the indicator cover of the part, which, when the fuse is activated or by emergency release of pressure, pushes out the fuse cover and thus disconnects (ruptures) the tested conductor. By breaking this wire, the communication in the monitored loop will be "opened". The indicators / controllers record this contact opening and provide further preset steps. Pressure fuses (also known as burst fuses) are designed to reliably release overpressure in the system in the event of an emergency.
BP 520 Burst Plugs with indication
PERFORMANCE CHARACTERISTICS
|
Construction material - bodies
|
304 stainless steel
|
|
|
Construction material - membranes
|
Inconel
|
|
|
Disk size:
|
3/16" (4.8 mm) disk
|
|
| Process connection: | 1/2-20 UNF-A threaded | |
| Accuracy: | ±10% @ 300°C (750°F) | |
| Immersion depth: | Optional dive length (before ordering) | |
Approval and certification: |
||
| ISO: | ISO 4126-6:2003(E) | |
| CE: | ||
| PED 97/23/EC, modules B&D | ||
| Burst plugs certification: | Each unit is certified | |
| Mounting torque: | Do not exceed 300 in / lbs. |
Burst plugs dimension:
Certification & Approval
|
|
EU Declaration of Conformity |
|
|
ISO 9001:2015 |
|
|
EAC - The Eurasian Conformity mark |
|
|
