VIATRAN

Kompanija VIATRAN

VIATRAN je svjetski lider u pružanju inovativnih senzora za mjerenje tlaka i razine. Naši visoko precizni i robusni senzori za tlak pružaju ponovljiva mjerenja u širokom rasponu tlakova i temperatura. Senzori za tlak tvrtke Viatran nude mV/V i mA izlaze zajedno s raznovrsnim električnim priključcima i armaturama za priključke tlaka. Naša linija proizvoda senzora za tlak obuhvaća standardne senzore za tlak, visoko precizne senzore za tlak, senzore za diferencijalni tlak, potopne senzore za tlak, senzore za procesni tlak, sanitarno- higijenske senzore za tlak, senzore za tlak pod žbukom, senzore za tlak u zahtjevnim uvjetima i specijalne senzore za tlak.

Tijekom pola stoljeća, Viatran je mjerio tlak, mjerio razine, ekstremne temperature i brze odzive u nekim od najzahtjevnijih aplikacijskih okruženja - visoko korozivnim medijima, štetnim učincima poput cikličkog tlaka i snažnih udara ili vibracija. Senzori za tlak tvrtke Viatran i senzori za razinu hladnoće namijenjeni su primjenama poput naftnih i plinskih usluga, proizvodnje čelika, prehrambene i medicinske opreme, tlakovnog lijevanja, kemijske industrije i raznih ispitivanja u automobilskoj i zrakoplovnoj industriji.


Model 574 Pressure Transmitter

Low Range Differential Pressure, Hazardous Location Approval

Viatran’s 574 Series differential pressure transmitters are extremely accurate and durable units, designed specifically for test applications. 574 comes with hazardous location option and has sealed external zero and span adjustments. The variable capacitance sensing technology provides extremely high overpressure protection, and long range stability, as well as high accuracy of 0.15% BFSL.

High Accuracy

Many Options available

ShuntCal

Low Pressure Applications

Model 551 Pressure Transmitter

Flush Mount Sensor, 0-50 thru 1000 psi, Solid Machined Diaphragm, Sealed External Adjustments

551 is designed to provide rugged performance while measuring harsh corrosive materials. The sensor is a stainless steel machined diaphragm, with no oil fill. The zero cavity flush sensor provides an easy clean surface with no clogging. Magnetically coupled external adjustments prevent fluid ingress while providing a rangeable, field adjustable solution.

All Stainless Steel construction

Model 550 Pressure Transmitter

Flush Mount Sensor, 0-50 thru 1000 psi, Solid Machined Diaphragm

550 is designed to provide rugged performance while measuring harsh corrosive materials. The sensor is a stainless steel machined diaphragm, with no oil fill. The zero cavity flush sensor provides an easy clean surface with no clogging.

All Stainless Steel construction

Model 572 Pressure Sensor

Secondary Containment to 40K, Hastelloy Wetted Materials, Hazardous Location Approvals

572 is designed with a secondary containment pressure feature which can withstand 40K of pressure. Available ranges from 0-100 thru 20K, designed for safety critical applications in oil services. Sealed external adjustments are standard with this model, and a wide variety of electrical and process connections are available as options.

ShuntCal

IP-68 Rated

High Pressure Applications

Model IGP10 Pressure Transmitter

Silicon sensor technology and microprocessor-based electronics

The Viatran IGP10 pressure transmitter utilizes field-proven silicon strain gauge technology for the reliability and performance that upstream oil and gas production pressure measurement demands:

High Accuracy

Many Options available

Model 544 Pressure Transducer

4-20 mA, 5" WC to 100 psi, Hazardous approvals

Viatran’s Model 544 is a low pressure gage transmitter designed for precise measurement in hazardous locations. External adjustments allow for field calibration and ranging to provide measurement flexibility.

High Accuracy

Many Options available

Model 970 Pressure Transmitter

HART® output, 0-100 thru 100K psi, Hazardous Location Approvals

Designed for applications including offshore oil rigs, oil production platforms, natural gas pipelines and rig safety systems, 970 uses a solid machined stainless steel diaphragm.

High Accuracy

Many Options available

All Stainless Steel construction

IP-68 Rated

High Pressure Applications

Model 571 Pressure Transmitter

Sealed External Adjustment, Hazardous Approvals, 0-100 thru 100K psi

571 is Viatran's answer to the requirement for Hazardous Location approvals with external sealed adjustments. 571 is rangeable, offering the user flexibility if measuring different pressure levels.

Many Options available

ShuntCal

All Stainless Steel construction

High Pressure Applications

Model 848 Pressure Transmitter

mv/V output, Hazardous Location Approvals, 0-1.5 thru 5K psi

848 is a mv/V output, oil fill sensor with hazardous location approvals. In ranges from 1.5 to 5K, the 848 is available in Vacuum, Absolute and Gage formats to cover a broad spectrum of applications.

High Accuracy

Many Options available

All Stainless Steel construction

ShuntCal

Model 748 Pressure Transmitter

0-5 Vdc, Hazardous Location Approvals, 0-1.5 thru 5K PSI

748 has hazardous location approvals, optional zero and span adjustment and can measure pressures as low as 1.5 psi. Compound ranging, negative outputs, a variety of pressure and electrical connections are examples of options that are available to customize the 748 to your exact requirements

High Accuracy

Many Options available

All Stainless Steel construction

Shunt Calibration circuit option

stainless

Model 548 Pressure Transmitter

mA output, 0-3 thru 0-5K psi, Hazardous Approvals

548 has the approvals necessary for use in hazardous areas. Viatran offers a variety of standard options and our ability to modify our products provides flexibility to meet your specific application needs.

High Accuracy

Many Options available

All Stainless Steel construction

Shunt Calibration circuit option

stainless

Model 870 Pressure Transmitter

mv/V output, 0-100 thru 100K psi, Hazardous Location Approvals

870 employs a solid machined diaphragm sensor which provides a rugged and reliable solution with excellent repeatability and resistance to pressure spikes. 870 hazardous approval options include Intrinsically safe and Explosion proof for US, Canada and Atex.

Many Options available

All Stainless Steel construction

IP-68 Rated
