VIATRAN

Barometric Pressure Transmitter Model 38H

Model 38H Barometric Pressure Transmitter

Viatran's Model 38H pressure sensor is among our most accurate pressure transmitters for industrial test and research applications. The 38H measures barometric pressure from 25" to 32" HgA with Improved Accuracy of ≤±0.06% FSO available.

Inquiry system

Configure your own product according to your requirements and needs. If you are unsure of the configuration, provide us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative Viatran product. If your request is urgent, let us know. We will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences, which is in stock and you can have another product available the next day.

If you need more information do not hesitate to contact us.

Viatran Configuration Code:

Your personal data will be processed according to Terms of personal data processing..

PERFORMANCE


Full Scale Pressure Ranges:

25" to 32" HgA
(Optional ranges can be factory set from 0” to 32” HgA with a minimum 7” HgA span)

Nonlinearity (Best Fit Straight Line):
≤±0.1% FSO (≤±0.06% FSO with DN option)


Accuracy (RSS*):

≤±0.21% FSO**

Repeatability:
≤±0.13% FSO each

Hysteresis:

≤±0.13% FSO each

Full Scale Output (FSO):

16 mA ≤±0.5% FSO at 70°F (21°C)
  Long Term Stability: ≤±0.5% FSO per 6 months (typical)
Compensated Temperature Range: 32°F to 170°F (0° to 77° C)
Process Media Temperature Range: -40°F to 250°F (-40°C to 121°C)
Ambient Operating Temperature Range: -40°F to 185°F (-40°C to 85°C)
  Storage Temperature Limits: -40°F to 185°F (-40°C to 85°C)
Temperature Effect on Zero: ≤±0.01% FSO per 1°F (.556°C)
Temperature Effect on Span: ≤±0.01% FSO per 1°F (.556°C)

ELECTRICAL


Supply Voltage:
8 to 30 Vdc

Power Supply Regulation:
≤±0.01% FSO per volt change over the supply voltage range

Output Signal:
4 - 20 mA
Load Resistance: 1050 Ohms max at 30 Vdc


Circuit Protection:

Input polarity may be reversed. Output may be short-circuited indefinitely Over voltage protection to 1000 volts according to EN61000-4-5


Insulation Resistance

<5 nS to case ground


Response Time

<2 mSec to reach 90% of full scale


RFI / EMI Suppression

CE EMC compliant per IEC EN 61326-1 & 61326-2-3 Annex BB, CE marked


Electrical Connection

Bendix / Amphenol PT02E-10-6P, mates PT06E-10-6S (SR)

Pin Outs

Pin A + Power / Signal
Pin B - Power / Signal
Pin C No Connection
Pin D No Connection
Pin E No Connection
Pin F No Connection

Shell

Ground

MATERIALS OF CONSTRUCTION

Wetted Parts
316 stainless steel

Housing
304 SS with an Aluminum alloy, black zinc-cobalt plated electrical connector
Weight
10 oz (283 g)
Identification Laser etched onto body

MECHANICAL


Pressure Connection:
1/4" - 18 NPT female

Proof Pressure:
45 PSI (92 HgA)

Burst Pressure:
75 PSI (153 HgA)

Pressure Cavity Volume:

1.5 mL

Mounting:

May be supported by process piping

OPTIONS

BF

(K)PTIH-10-6


BG

DIN 43650


BL

WK6-32S


BN

(K)PTIH-8-4P


BQ

(PT02H-10-6P


BR

CF3102E-14S-6P


ZU

Direct Cable: 175°F (79°C) max temperature


Y( )

Multiple pressure ports available. Consult factory


DC

Extended temperature operation: -40°F to 170°F (-40°C to 77°C)]


DG

Improved temperature compensation ( ± 0.5% FSO per 100°F (55.5°C) zero and span shift)


DH

Special ranging


DM

Modified full scale output


DN

Improved Accuracy (Non Linearity) ≤±0.06% FSO


DQ

Cleaning for oxygen service


EA

Special calibration run
  NH Customer specified identification


PW

Scaled with Process Meter


Note:

Application of some available options may affect standard performance. Consult your Viatran representative for details.

DIMENSIONS
