Filtration systems and screencangers for industrial applications
Filtration is a process that separates or purifies substances. The mechanical separation processes of Maag filtration systems are physical. The principles are used in filters and screen converters for separating and cleaning plastic melts, chemicals and lubricants. They are also used in recycling, extrusion, rotational molding, in general in industrial applications and in the pharmaceutical and food industries.
HSC
Manual screen changer and plate screen changer for filtration solutions and extrusion processes
Manual screen changers from MAAG have been the first choice of cost-effective filtration systems in extrusion lines for many years. Starting at size 45, the manual screen changers optionally come with transmission gearing.
Simple operation with quick screen change
High operational reliability
Short material residence time
Leak-free mode of operation
Low pressure consumption
Flow channel geometry without any dead spots
SSC
Effective single piston screen changer for reliable melt cost effective filtration solution
The compact single-piston screen changers SSC from MAAG provide a cost-effective filtration alternative for extrusion applications which allow for interruptions in the melt stream during screen changeovers. SSC operate without any additional seal.
Simple operation and uncomplicated screen changing
High operational reliability
Short material residence time
Leak-free mode of operation
Low pressure consumption
Flow channel geometry without any dead spots
CSC
Continuous screen changer and double pistion screenchanger system for filtration - CSC
Continuous CSC screen changers from MAAG with their robust and leak-free operation meet highest quality standards with respect to melt filtration systems. Because of their constantly improved functionality, continuous screen changers from Maag increase product quality significantly. CSC screen changers
Simple operation and uncomplicated screen changing
High operational reliability
Short material residence time
Leak-free mode of operation
Low pressure consumption
Flow channel geometry without any dead spots
DSC
Single piston screen changer for filtration systems and demanding extrusion process
The discontinuously operating single piston screen changer, equipped with a screen cavity, offers a robust and economic alternative for extrusion and compounding applications which permit a brief interruption in the melt flow when changing the screen.
Simple operation and uncomplicated screen changing
High operational reliability
Short material residence time
Leak-free mode of operation
Low pressure consumption
Flow channel geometry without any dead spots
FSC
Hydraulic screen changer for filtration systems and polymer production
FSC hydraulic screen changers from MAAG are equipped with a pressure-adaptive sealing system as a standard for filtration systems. Thanks to this sealing system, the required sealing forces are automatically adjusted by the screen changer to the actual melt pressure.
Simple operation and uncomplicated screen changing
High operational reliability
Short material residence time
Leak-free mode of operation
Low pressure consumption
Flow channel geometry without any dead spots
Short residence time
CSC-C
Screen changer with candle filter elements
MAAG’s CSC-C large scale screen changer with candle filter elements is the right choice if short melt residence time, small footprint and a simplified candle change are required.
Filter elements
Vertical / horizontal installation
2/4 pistons
Patented design
CSC-R
A Double pistion screenchanger for flitration systems
Large-area screen changers from MAAG are based on the sturdy and proven double-piston screen changer design. The patent-registered curved screen plate provides four times more active screen area than a conventional screen changer with circular screen cavities. The highly compact
Up to 4x more filter area than circular screen cavities
Higher throughput
Multiplied screen life time
Smaller hydraulic unit
Lower melt pressure
Higher filtration fineness
Reduced flux rate kg/h/cm2
Ultra-compact design
Less heating capacity
CSC/BF-4F
Automtic self cleaning screen changer for polymer extrusion industry and filtration systems
MAAG backflush automatic self cleaning screen changers are based on the proven double-piston design which operates without any mechanical seals. The screen changers are equipped with four screen cavities. This design is used mainly in recycling applications for filtration systems.
Multiple screen usage
Simple operation and uncomplicated control
High operational reliaility
Short material residence time
Leak-free mode of operation
Low pressure consumption
Flow channel geometry without any dead spots
FSC-OEM
Optimized flat screen changer for processing of plastics
The flow optimized new version of MAAG´s FSC hydraulic and manual screen changers assist operators of plastic extrusion lines in achieving a reduced equipment footprint, reduced residence time and improved residence time distribution.
Reduction of pressure loss
Optimized flow
Increased production speed
Energy efficiency
Elimination of pressure fluctuations
Reduction of material consumption
Easy maintenance
High Performance Melt Filter ECO
The continuous melt filters of the ECO series are mainly employed in PET and PA applications due to their special design and for filtering polymer feedstock from industrial waste with a low level of contamination or lightly contaminated post-consumer waste, as well as for clean virgin material. Our ECO melt filters are capable of processing a wide range of polymers. All solid or elastomer foreign particles such as gels, black specs, paper, wood, aluminum, copper, rubber, silicone or high-melting polymer composites are efficiently removed.
Continuous operation with a constant pressure on the outlet side
No need to replace the screen for several weeks, or possibly months, depending on the material and the applicationExtremely low melt losses
Absolutely clean filtration surface during the total time in operation
Up to 1.5% contaminants removed (we recommend our ERF filter for higher contaminant contents)
Completely closed system with no entrapped air
Short contaminant residence times in the filter
Consistent melt flow without dead zones or degraded polymer
Suitable for all polyolefins, polystyrenes, PET and PA
Better mixing and homogenizing of highly filled melts
High Performance Melt Filter ERF
The continuous melt filters in the ERF series are suitable for materials with up to 16% by weight contamination and are guaranteed to remain in use for long periods without changing the filter. Our ERF melt filters are capable of processing a wide range of polymers (e.g. LDPE, LLDPE, HDPE, PP, PS, ABS, PC / ABS, TPE, TPU, POM). All solid or elastomer foreign particles such as paper,wood, aluminum, copper, rubber, silicone, or high-melting polymer composites are efficiently removed.
Fully automatic, continuous operation
Up to 18% contaminants removed
Extremely low melt losses
More reliable processing due to constant pressure at the filter outlet
No need to replace the screen for several weeks, or possibly months, depending on the material and the application
Completely closed system with no entrapped air
Short contaminant residence times in the filter
Very simple replacement of the scraper from outside using a hydraulic cylinder
Elastomers (rubber, silicone) are efficiently filtered and discharged before they have a chance to be forced through the filter screen
simplex
Discountinuous large area polymer filtration applications for industry and extrusion
MAAG-designed simplex polymer filter systems can be provided with either fixed or removable vessels. A compact preheat station with spare vessel is also available for locating near the polymer processing line for quick changeout. They are custom designed to minimize
Lower cost
Easier operation
No diverter valves
Less space requirements
Minimized pressure drop
Horizontal or vertical design
