M-ASG
The proven WSG dry-cut pelletizing and strand pelletizing systems with M-ASG pelletizers produce top-quality cylindrical pellets that are ideal for further processing.
M-ASG
M-ASG
M-ASG
Inquiry system
Configure your own product according to your requirements and needs. If you are unsure of the configuration, provide us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative MAAG products. If your request is urgent, let us know. We will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences.
If you need more information do not hesitate to contact us.
Configuration code
TECHNICAL DATA
| M-ASG 600 | M-ASG 900 | |||
| Operating width: | 600 mm | 900 mm | ||
| Drive system: | AC motor with belt drive | AC motor with belt drive | ||
| Motor power of pelletize: | 22-45 kW | 30-75 kW | ||
| Line speed at pellet length of 3 mm: | 30-120 m/min | 30-120 m/min | ||
| No. of strands at a 75 % utilization rate and a pellet diameter of 3 mm: | 150 | 225 | ||
| Throughput rates | ||||
| Product: | Density [g/cm3] | M-ASG 600 | M-ASG 900 | |
| PP, PE: | 0,91 | 6000 | 9000 | |
| GPPS, SAN: | 1,04 | 7000 | 10 500 | |
| ABS, HIPS: | 1,04 | 7000 | 10 500 | |
| PMMA: | 1,18 | 7000 | 10 500 | |
| PC: | 1,20 | 7000 | 10 500 | |
| PET, PBT, PC: | 1,31 | 8500 | 12 500 | |
| PA 6, PA 6.6: | 1,14 | 6000 | 9000 | |
| PET, PBT, PA, PP + 15 bis 50 % glass fi ber: | 1,00 | 5000 | 7500 | |
| 1,55 | 6300 | 9500 | ||
| * Pellet length 3 mm, pellet diameter 3 mm, and maximum number of strands | ||||
