Dry cut

Strand pelletizer for strand pelletizing and dry cut pelletizing for compound production – SGS 100/200/300-E6

SGS 100/200/300-E6

More than thousand machines in operation: The cantilvered pelletizers of the SGS-E series demonstrate their quality under the toughest production conditions for strand pelletizing and dry cut pelletizing — since the beginning of the 1980s. A sturdy and sophisticated design as well as many technical details for improved accessibility when cleaning and/or changing products reduce unproductive downtime and make the SGS-E the preferred pelletizer for production of masterbatches and small lots. The improved cutting geometry extends the production range especially when processing soft, elastic, and very brittle materials.

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

SGS 100/200/300-E6

Inquiry system

Configure your own product according to your requirements and needs. If you are unsure of the configuration, provide us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative MAAG products. If your request is urgent, let us know. We will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences.

If you need more information do not hesitate to contact us.

MAAG Configuration code

Your personal data will be processed according to Terms of personal data processing..

​​TECHNICAL DATA

  Parameters: Units: SGS 100-E6

 SGS 200-E6

SGS 300-E6
  Working width: mm 100 200 300
  Max. No. of strands: Ø 3 mm 20 40 60
Strand speed: m / min 20-80 20-80 20-80
  Type of drive: Frequency converter
  Power: kW 3,0 5,5 11,0
  Max. throughput (product-depently): 1,2kg / h 600 1200 2000
  Acoustic insulation: if required
