Temperature sensors

TI422J

TI422J

The TI422J is an alternative thermocouple that allows you to easily and quickly adjust the dive length to suit any application. The thermocouple can be specified with either a 20 cm spring bayonet cap that allows up to 17 cm of adjustable immersion, thanks to a bayonet lock on the flexible armor to allow the full immersion length "B". Dynisco thermal thermocouples are designed and manufactured to applicable ISA standards to the National Institute of Standard Technology (NIST)

TI422J - Dynisco Temperature Sensors

TI422J - Dynisco Temperature Sensors

Cables to dynisco temperature sensors

Cables to dynisco temperature sensors

Cables to dynisco temperature sensors

Cables to dynisco temperature sensors

Cables to dynisco temperature sensors

Cables to dynisco temperature sensors

Inquiry system

Configure your own product, according to your requirements and needs. If you are not sure about the configuration, tell us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative Dynisco product. If your request is urgent, let us know, we will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences, which is in stock and you can have the necessary product the next day.

Konfigurační kód


PERFORMANCE CHARACTERISTICS



Type:
S = Bayonet end and 20 cm spring
A = Bayonet con. and flexible armor
Wire:
060 = 12 cm long
120 = 30 cm long
Temperature range:
0 to 480°C
  Terminals: 0 = Stripped wires 5 cm length
1 = Standard type J male TC connector
  Optional:

P2B = Bayonet cap with an outer tip diameter of 3.8 cm and an outer diameter of 6.4 cm of flexible armor

P3B = Bayonet saddle cap with probe outer diameter 5.7 cm and outer diameter 6.4 cm of flexible armor

  Sensor type: 1-wire STD, Two-wire, 2-wire RTD, 3-wire RTD, 2 Dual RTD, 3 Dual RTD



SENSOR DIMENSIONS:



Transducer Mounting Hole Cleaning Tool Kit

Installation of transducers into improperly cleaned or sized holes is one of the major causes of damage to these instruments. With this kit, the .312" tip diameter hole, the 45 degree seating surface, and the .451" hole can be cleaned. The kit includes a gauging plug which is used to verify that the hole has been correctly machined and cleaned. M10 and M18 cleaning kits also available.


Transducer Mounting Hole Machining Tool Kit

The Dynisco Transducer Mounting Hole Machining Tool Kit contains all of the necessary drills and taps to prepare a standard 1/2 - 20 UNF transducer mounting hole and the 45 degree seat. All tools included in this kit are made of premium grade, high strength tool steel. Care should be taken in the use of proper speeds and feeds, lubricants, and a method to assure continual alignment of each progressing tool. M10 and M18 kits are also available.

Temperature Controller 1496 Series

The 1496 series temperature controllers represent an economical solution for precise temperature control of the machine. Thanks to its DIN size and several output configurations, the controller is suitable for twin and single screw extruders, both for screw temperature zones and for adapter zones, together with heating / cooling for individual zones.

Temperature Controller 1498 Series

The 1498 series temperature controllers represent an economical solution for precise temperature control of the machine. Thanks to its DIN size and several output configurations, the controller is suitable for twin and single screw extruders, both for screw temperature zones and for adapter zones, together with heating / cooling for individual zones.

UPR 900 Panel Indicator

The Dynisco UPR900 is a compact 1/4 DIN process indicator. The UPR900 can display your preferred production process values. Optional secondary input for displaying the temperature or pressure of the polymer melt all in one place. The secondary input can be a strain gauge to measure the differential pressure in the process. The UPR900 contains two standard assigned alarms with the option to add a third alarm.

ATC990 Process Controller

The ATC 990 series controller is a time-tested product that has received a new design and new functions. Compared to classic features such as pressure, temperature and alarm setting options, these new models are enhanced with the ability to monitor and record parameters to a USB drive, the undeniable advantage is the large display and interactive environment when setting up the controller.
