Strand pelletizing

Underwater and dry cut pelletizing system – Dry Cut “WD” Series

EBG Belt Conveyor Pelletizing System

The belt conveyor pelletizing system EBG is specifically designed for the compounding of water-sensitive or highly filled (> 60 %) or fragile products in strand pelletizing and dry cut pelletizing. Variable system configuration permit a perfect adaptation to the product to be processed. Using the belt conveyor, even elastic and very flexible polymers may be handled easily and efficiently.

Inquiry system

Configure your own product according to your requirements and needs. If you are unsure of the configuration, provide us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative MAAG products. If your request is urgent, let us know. We will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences.

If you need more information do not hesitate to contact us.

Configuration code

Your personal data will be processed according to Terms of personal data processing..

​​TECHNICAL DATA

  Model:  EBG 60 EBG 100 EBG 200
Strand pelletizer: Primo 60  Primo 100 Primo 200
Belt type: STB 250 STB 250  STB 450
  Operating with belt: 250 mm 250 mm 450 mm
  Belt motor power: 0.55 kW 0.55 kW 0.55 kW
  Line speed: 8-80 m/min 8-80 m/min 8-80 m/min
  No. of strands (at 3mm pellet diameter): 5-8 10-20 20-40
  Length of conveyor belt: 3, 5 or 7m 3, 5 or 7m 3, 5 or 7m
  Throughput at density 1.4 kg/dm 3: 100-300 kg/h 200-800 kg/h  400-1,600 kg/h
