Pultrusion

Dry cut pelletizing and strand pelletizing for all cases of application – PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

During production of LFT long-fi ber pellets using the pultrusion method, fi ber strands are drawn continuously through a polymer melt and the individual fi bers are embedded in the polymer matrix. After cooling, the resulting fi ber/polymer strands are chopped continuously to form pellets. Our LFT rotors fi t our PRIMOPLUS and M-ASG pelletizing systems.

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

PRIMOPlus for pultruded LFT pellets

Inquiry system

Configure your own product according to your requirements and needs. If you are unsure of the configuration, provide us in the notes the necessary information about the existing sensor or product, even a competitor. We will be happy to help you find an alternative MAAG products. If your request is urgent, let us know. We will do our best to help you resolve this situation to your satisfaction as quickly as possible. If we have all the information, we are able to offer a model with minor differences.

If you need more information do not hesitate to contact us.

MAAG Configuration code


TECHNICAL PARAMETERS

    PRIMOPlus 100 PRIMOPlus 200 PRIMOPlus 300 PRIMOPlus 400 PRIMOPlus 600
Feed width: 100 mm 200 mm 300 mm 400 mm  600 mm
  Drive system: AC motor with gear or belt drive AC motor with gear or belt drive AC motor with gear or belt drive AC motor with gear or belt drive AC motor with belt drive
  Drive power: 3 - 5.5 kW 5.5 - 7.5 kW 7.5 - 11 kW 11 - 18.5 kW 15 - 30 kW
  Feed speeds: 5 - 50* m/min 5 - 50* m/min 5 - 50* m/min 5 - 50* m/min 5 - 50* m/min
  No. of strands: 15 25 40 60 80
  Pellet length: 5 - 15 mm 5 - 15 mm 5 - 15 mm 5 - 15 mm 5 - 15 mm
